1007 DC Millivolt Calibrator

Time Electronics 1007 便携式电压电流校准仪，3 ranges up to 1 V

产品概述

The 1007 is a handheld calibrator that can be used for potentiometric voltage measurement in addition to its operation as a millivolt source. The null zero and sensitivity are adjustable via front panel controls. Maximum sensitivity enables null balance to resolve 3 microvolt. 主要特点：3 ranges up to 1 V；20 mA output current；Short circuit and overload protection；LED null measuring

技术参数

Output Voltage Stability	Less than 60 ppm/°C. Less than 100 ppm per 3 months (non-cumulative).Specifications
Output Polarity	Positive or negative switch selected. A centre ‘off’ position is also provided.Specifications
Output Noise Level	Less than 30 ppm of full scale.Specifications
Reference Source	Precision bandgap reference diode, for stability and low temperature coefficient.Specifications
Operating Temperature	-10 °C to +60 °CSpecifications
Dimensions	H 200 x W 75 x D 110 mm (H 215 x W 100 x D 120 mm including protective cover)Specifications
Weight	0.75 kg (1.2 kg including protective cover)Specifications
Supplied With	Protective cover (fitted), 6 x AA batteries (installed), and user manualSpecifications
Optional Extras	Carry case (protective cover is removed when used). Rechargeable battery pack with mains charger. Calibration certificates: Traceable (factory) and accredited (ISO 17025).Specifications
Country of Origin	UKSpecifications
Shipping Details	Packed Dimensions: L 31 x W 24 x H 25 cm / Packed Weight: 3 kgSpecifications
HS Code	9030 3370Specifications
9027	Carry caseSpecifications
9529	Rechargeable battery pack - (6 NiMH Cells + Mains Charger)Specifications
C150	Traceable calibration certificate (Factory)Specifications
C101	Accredited calibration certificate (ISO 17025)Specifications
1007 DC mV Calibrator Data Sheet	473 kB / EN ES / PDFSpecifications
1007 DC mV Calibrator User Manual	1.1 MB / EN / PDFSpecifications
型号	1007Models
