5025C
5025C Multifunction Calibrator
Time Electronics 5025C 多功能校准仪，15 ppm precision calibrator
产品概述
The 5025C Series 2 is a multifunction calibrator that provides a wide range of precision outputs for the calibration of electrical test tools, meters, and various types of measuring devices. It combines performance and functionality with simple operation, making it suitable for calibration laboratories, workshops and on-site test facilities. 主要特点：15 ppm precision calibrator；0 t
技术参数
| Voltage DC | 0 to ± 1050 V / ± 15 ppm of settingSpecifications |
|---|---|
| Current DC | 0 to ± 22 A 1000 A with clamp meter adaptor (option 9780) / ± 60 ppm of settingSpecifications |
| Voltage AC | 2 mV to 1050 V / 20 Hz to 1 MHz sine-wave / ± 0.05 % of settingSpecifications |
| Current AC | 10 μA to 22 A / 20 Hz to 5 kHz sine-wave 100 A with current transformer (option 9790) 1000 A with clamp meter adaptor (option 9780) / ± 0.05 % of settingSpecifications |
| Digital frequency | 0.1 Hz to 10 MHz / ± 20 ppm of settingSpecifications |
| 2-wire variable resistance | 1 Ω to 1.1 GΩ / ± 100 ppm of settingSpecifications |
| 4-wire decade resistance | 1 Ω to 100 kΩ / ± 30 ppm of settingSpecifications |
| RTD simulation | –180 to 850 °C. Type Pt100, Pt200, Pt500, Pt1000 / ± 0.03 °CSpecifications |
| Thermocouple simulation | –210 to 2315 °C. Type J, K, R, T, S, B, E, N, C, L, U / ± 0.05 °CSpecifications |
| Capacitance | 1nF, 10nF, 20nF, 50nF, 100nF, 200nF, 500nF, 1μF, 10μF, 20μF, 50μF, 100μF / ± 0.2 % of settingSpecifications |
| Inductance | 1mH, 1.9mH, 5mH, 10mH, 19mH, 50mH, 100mH, 190mH, 500mH, 1H, 10H / ± 0.1 % of settingSpecifications |
| Power | 22 A, 1050 V, 23 kW, 40 to 500 Hz / ACV: 0.05 %, DCV: 0.01 %. ACI: 0.1%, DCI: 0.05 %Specifications |
| Phase / Power factor | ± 90.0° / 0.00 to 1.00 PF / ± 0.25°Specifications |
| Option 9780: Clamp meter adaptor | AC/DC Current up to 1000 A (DC, 45 to 90 Hz) / ± 0.5 %Specifications |
| Amplitude | 2 mV to 200 V (1 M Ω) and 1 mV to 2 V 50 Ω (Square-wave or DC) / ± 0.05 %Oscilloscope Calibration (5025C-S2/SCP) |
| Duty cycle | 3 frequencies: 100 Hz, 1 kHz, 10 kHz, settable from 0 to 100 % / –Oscilloscope Calibration (5025C-S2/SCP) |
| Fast-rise | < 400 ps. Bandwidth checking up to 400 MHz / –Oscilloscope Calibration (5025C-S2/SCP) |
| Levelled sine wave | 50 to 1000 kHz and 10 MHz to 2.2 GHz levelled sine-wave (0.35 to 3.5 V pk-pk) / Amplitude ± 0.5 %, Frequency ± 50 ppmOscilloscope Calibration (5025C-S2/SCP) |
| Mains voltage | 100 to 260 V AC 50/60 HzSpecifications |
| Fuse ratings | 3.15 A anti-surgeSpecifications |
| Power consumption | 120 W typical, 200 W maximumSpecifications |
| Temperature performance | Operating: 10 to 40 °C. Storage: –10 to 50 °CSpecifications |
| Operating humidity | < 80 % non condensingSpecifications |
| Altitude | 0 to 3 km. Non operating: 3 to 12 kmSpecifications |
| Interfaces | RS-232, GPIB and USB (via RS-232 adaptor). Command set: Standard SCPISpecifications |
| Dimensions / Weight | W 447 x H 152 x D 470 mm. Weight: 16.5 kgSpecifications |
| Supplied accessories | Premium test lead set (S2PTL), calibrator control software, RS-232 cable, RS-232 to USB adaptor, user manual.Specifications |
| Country of Origin | UKSpecifications |
| Shipping Details | Packed Dimensions: L 66 x W 71 x H 42 cm / Packed Weight: 24 kgSpecifications |
| HS Code | 9030 3900Specifications |
| 9762 | Rubidium high stability frequency reference (for use with 5025C-S2/SCP models) - View data sheetAdaptors, accessories and options |
| 9764 | Current probe calibration adaptor (for use with 5025C-S2/SCP models) - View data sheetAdaptors, accessories and options |
| 9773 | Optical tacho adaptor - View data sheetAdaptors, accessories and options |
| 9780 | Clamp meter adaptor (1 and 50 turn coil) - View data sheetAdaptors, accessories and options |
| 9790 | 100 Amp AC current transformer - View data sheetAdaptors, accessories and options |
| 9085 | Soft carry caseAdaptors, accessories and options |
| 9059 | Hard transit case - View data sheetAdaptors, accessories and options |
| 9728 | 19 " universal rack mount kitAdaptors, accessories and options |
| EW01 | Extended warranty - 3 years total covering parts and labour.Adaptors, accessories and options |
| ECFL-RN1Y/1L | EasyCal Calibration Software - 1x Full user license (renewal subscription type). Recurring payment every 12 months. Ongoing support contract included. License key type: USB dongle.EasyCal software licenses |
| ECFLA | EasyCal Calibration Software - 1x Full user license (perpetual lifetime type). One-time payment. 1 year support contract included. License key type: USB dongle.EasyCal software licenses |
| 9795 | Printer and connectivity kit - View data sheetEasyCal accessories |
| 9777 | Bar code reader - View data sheetEasyCal accessories |
| 9778 | Cal and ID label printer - View data sheetEasyCal accessories |
| 9779 | Job and address label printer - View data sheetEasyCal accessories |
| 9597 | GPIB cableEasyCal accessories |
| 9794 | GPIB to USB adaptorEasyCal accessories |
| 5025C-S2 Multifunction Calibrator Data Sheet | 550 kB / EN / PDFSpecifications |
| 5025C-S2 Multifunction Calibrator Extended Specifications | 390 kB / EN / PDFSpecifications |
| 5025C-S2 Multifunction Calibrator User Manual | 5.5 MB / EN / PDFSpecifications |
| 50XX-S2 Calibrator Control Software User Manual | 16 MB / EN / PDFSpecifications |
| EasyCal Calibration Software Brochure | 10 MB / EN / PDFSpecifications |
| 型号 | 5025CModels |
